| Connection type | CaseC (Cable version/5m cable) Or CaseB (Socket version) |
| Power rating | 22+22kW max. (44kW max. total) |
| Rate current per cable | 2 x 32A max. |
| Input voltage / Frequency | 400Vac±10% / 50/60Hz |
| Installation method | Wall-mounting or Column-mounting (Pole is optional accessory) |
| Number of connectors or sockets per charge post | 2 |
| Cable Length | 5m |
| Dimensions (WxHxD） | 395 x 504 x 197mm |
| Footprint (regarding to pole) | 366 x 206mm |
| Foundation type | Concrete foundation |
| Configurations per charge post (Single or Dual, AC type 1 or type 2, etc..) | Dual/AC type 2 |
| Simultaneous Charging | Yes |
| Satellite or standalone | Approx. 10kg (CaseB) Approx.15kg (CaseC) |
| Weight | Approx. 5.6Kg |
| Charging Mode | Mode 3 |
| Max. altitude | ≤ 3000 m |
| IK level (impact) for charger | IK10 |
| Operation Temperature | -30℃ - 50℃ |
| Storage Temperature | -40℃- 70℃ |
| Ambient temperature is lower than -30degC or higher than +50degC. | If overheat occurs, the charging process will be stopped. |
| Cable length including default and options, | 5m(default) Cable length could be customizable. |
| Load management solution package (per charger or per site) | yes |
| Integrate option that the display can show the charging process and the charging price that will be billed, real-time. (once off) | Yes |
| Remote update function for UI display (per version) | Yes |
| Cable Management solution Costs | Yes |
