1/1
| Input Voltage / Frequency | 400Vac±10% 50/60Hz |
| Satellite or standalone | Standalone (WallBox) |
| Dimensions (WxHxD) NOTE: Details please refer 2D Dimension drawing of each product. |
680*440*280mm |
| Output voltage | 200-1000Vdc |
| Charging Mode | Mode 4 |
| Cable Length | 3.4m |
| Weight | Approx. 35kg (Excluding power module) Note: Approx. 15kg / Power module |
| Max. altitude | ≤2000 |
| IK level (impact) for charger | IK10 (Housing) IK08 (Screen) |
| Noise level | <65dB@1m&full load |
| Foundation type | Concrete foundation |
| Input MCCB/MCB rating | 63A 4P |
| Casing (Housing) material | Aluminium |
| Housing colours | Sliver and Black combined |
| Operation Temperature | -30℃-50℃ |
| Storage Temperature | -40℃-70℃ |
| Ambient temperature is higher than +50 degC. | Ambient temperature is over 50℃, the Charger will be derating. Details could refer power module's derating curve. |
| Screen | Display screen: Screen size: 7 inches Brightness:400cd Touchable: Yes Display constrast:750 Operation Temp:-30℃~85℃ Power consumption: 12V/0.143A View angel (in °):80/80/80/80 |
| Dynamic power sharing | Replace shared evenly by Dynamic power sharing |
